Data Protection – Surge Suppressor 12 Lines

  • SKU: TS-12-24V
  • Stock Status: In stock

$318.75

Product Ships in 1-2 weeks.

The Data Protection – 12 Lines is a rugged surge suppressor designed for industrial data line protection. It supports 12 lines, features fast response and automatic recovery, and is housed in a sealed enclosure for water, dust, and oil resistance.

Quantity

Product Description

The Data Protection – 12 Lines is a high-performance surge suppressor designed to protect up to 12 data lines in commercial and industrial process control systems. Built to withstand harsh environments, its sealed enclosure prevents water, dust, and oil intrusion, ensuring long-lasting protection.

With a fast response time and automatic recovery, this device minimizes downtime while offering over-voltage transient protection. Designed for current loop applications, it features a nominal discharge current rating of 5kA (8/20µs impulse), ensuring reliable surge suppression.

Ideal for use with the Pipe Cleaner™, this unit also supports custom configurations for varying voltage requirements. The TS-12-24V ensures compliance with industrial-grade safety and durability standards.

Features:

  • Surge Suppressor – Protects up to 12 data lines from over-voltage transients
  • Optimized for Industrial Applications – Designed for commercial and industrial process control systems
  • Fast Response & Automatic Recovery – Ensures minimal downtime and reliable protection
  • Sealed Enclosure – Protects against water, dust, and oil intrusion for rugged environments
  • High Surge Capacity – Handles 5kA nominal discharge current (8/20µs impulse) for enhanced durability
  • Versatile Compatibility – Ideal for current loop applications and compatible with Pipe Cleaner™
  • Custom Configurations Available – Other voltage options and configurations available upon request

Specifications:

  • Clamping Voltage (Min): 30V
  • Line Voltage (Max): 24V
  • Residual Voltage: 35V (8/20µs impulse)
  • Nominal Discharge Current: 5kA (8/20µs impulse)
  • Protection Capacity: 12 lines
  • Response Time: Fast response with automatic recovery
  • Enclosure: Sealed for water, dust, and oil resistance
  • Optional Features: Low-capacitance diodes or multi-mode protection available
  • Dimensions: Length: 5.9 inches | Width: 3.3 inches | Height: 1.8 inches
