Streamer Retarding Air Terminal – Aluminum

Discover the exceptional protection of our Aluminum Air Terminal – a UL listed lightning rod engineered for top-tier performance in NFPA 780 or UL 96A systems. Boasting innovative streamer delaying electrodes, available in stainless steel, Hastelloy®, or titanium, this lightning rod ensures superior safeguarding. Tailor your solution with a range of lengths, each featuring a 1/2″ thread, lock washer, and jam nut. Elevate your lightning protection system with the unmatched reliability of streamer delaying and static dissipating qualities offered by our Aluminum Air Terminal.

Choose from a range of options to meet your specific requirements:

DAT-112A   1/2″ X 12″ aluminum terminal with 1/2″ thread, 1/2″ lock washer and jam nut.
DAT-118A   1/2″ X 18″ aluminum terminal with 1/2″ thread, 1/2″ lock washer and jam nut.
DAT-124A   1/2″ X 24″ aluminum terminal with 1/2″ thread, 1/2″ lock washer and jam nut.
DAT-136A   1/2″ X 36″ aluminum terminal with 1/2″ thread, 1/2″ lock washer and jam nut.
DAT-148A   1/2″ X 48″ aluminum terminal with 1/2″ thread, 1/2″ lock washer and jam nut.
DAT-160A   1/2″ X 60″ aluminum terminal with 1/2″ thread, 1/2″ lock washer and jam nut.

• Streamer Delaying & Static Dissipating: Blunt aluminum lightning rods with advanced streamer delaying electrodes.
• Material Options: Electrodes are available in stainless steel, Hastelloy®, or titanium.
• UL Listed: Ensures compliance and reliability in lightning protection systems.
• Various Length Options: Choose from 12″ to 60″ aluminum air terminals, each equipped with a 1/2″ thread, lock washer, and jam nut.
• Made in the USA: Every Streamer Retargeting Air Terminal is meticulously manufactured in the United States.

• Model: DAT-1xxA
• Main Material: Aluminum
• Post Length Options: 12”, 18”, 24”, 36″, 48”, 60″
• Hardware: Includes lock washer and jam nut
• Material Options for Electrodes: Stainless steel, Hastelloy®, or titanium
• Compliance: UL-96A, NFPA 780

Aluminum Air Terminal Spec Sheet
